Grail.Core.AIEntity Class Reference

Defines a basic object which can execute behaviors. More...

Collaboration diagram for Grail.Core.AIEntity:

Public Member Functions
	AIEntity (string name="")
	Constructs an AIEntity with the given name. More...
void	AddSharedBlackboard (string key, Blackboard blackboard)
	Inserts pair of key and blackboard into container of shared blackboards. More...
Blackboard	GetSharedBlackboard (string key)
	Gets shared blackboard identified by given key. More...
Behavior	MoveSuspendedBehavior ()
	Gets reference to a previously assigned behavior that has been suspended by a new one. More...
void	StageBehavior (Behavior behavior)
	Finishes the current behavior and starts a new one. More...
void	AddReasonerChangeObserver (IReasonerChangeObserver observer)
	Adds a reasoner change observer that will be notified via calling OnReasonerSet function when a new reasoner is be assigned to an entity. More...
void	RemoveReasonerChangeObserver (IReasonerChangeObserver observer)
	Removes a reasoner change observer so it won't be notified of reasoner changes anymore. More...

Static Public Member Functions
static void	ResetNextId (int nextId=0)
	Resets available entity IDs. Useful when the game should be restarted but entities were not destroyed, like ending Play in Editor or soft restarting level. More...

Public Attributes
Blackboard	Blackboard => blackboard
	Blackboard owned by this entity. More...
bool	HasActiveBehavior => currentBehavior != null
	Checks whether current behavior is not nullptr. More...
Dictionary< string, Blackboard >	SharedBlackboards => sharedBlackboards

Protected Attributes
readonly Dictionary< string, Blackboard >	sharedBlackboards
Reasoner	reasoner

Properties
string	Name [get]
	A name used for display and debug purposes. More...
Behavior	CurrentBehavior [get]
	get - Behavior currently assigned to this entity. More...
bool	HasStagedBehavior [get]
	Checks whether this entity has a behavior awaiting its execution. More...
int	Id [get]
	A unique integer id assigned by AIManager during construction. More...
Reasoner	Reasoner = nextEntityId++ [get, set]
	Reasoner assigned to this entity. More...

Detailed Description

Defines a basic object which can execute behaviors.

Constructor & Destructor Documentation

AIEntity()

Grail.Core.AIEntity.AIEntity ( string  name = "" )

inline

Constructs an AIEntity with the given name.

Parameters

name

Member Function Documentation

AddReasonerChangeObserver()

void Grail.Core.AIEntity.AddReasonerChangeObserver ( IReasonerChangeObserver  observer )

inline

Adds a reasoner change observer that will be notified via calling OnReasonerSet function when a new reasoner is be assigned to an entity.

Parameters

observer

AddSharedBlackboard()

void Grail.Core.AIEntity.AddSharedBlackboard ( string  key, Blackboard  blackboard  )

inline

Inserts pair of key and blackboard into container of shared blackboards.

Parameters

key
blackboard

GetSharedBlackboard()

Blackboard Grail.Core.AIEntity.GetSharedBlackboard ( string  key )

inline

Gets shared blackboard identified by given key.

Parameters

key

Returns

MoveSuspendedBehavior()

Behavior Grail.Core.AIEntity.MoveSuspendedBehavior ( )

inline

Gets reference to a previously assigned behavior that has been suspended by a new one.

Returns

RemoveReasonerChangeObserver()

void Grail.Core.AIEntity.RemoveReasonerChangeObserver ( IReasonerChangeObserver  observer )

inline

Removes a reasoner change observer so it won't be notified of reasoner changes anymore.

Parameters

observer

ResetNextId()

static void Grail.Core.AIEntity.ResetNextId ( int  nextId = 0 )

inlinestatic

Resets available entity IDs. Useful when the game should be restarted but entities were not destroyed, like ending Play in Editor or soft restarting level.

Parameters

nextId

Optional next available entity id

StageBehavior()

void Grail.Core.AIEntity.StageBehavior ( Behavior  behavior )

inline

Finishes the current behavior and starts a new one.

Parameters

behavior

Member Data Documentation

Blackboard

Blackboard Grail.Core.AIEntity.Blackboard => blackboard

Blackboard owned by this entity.

HasActiveBehavior

bool Grail.Core.AIEntity.HasActiveBehavior => currentBehavior != null

Checks whether current behavior is not nullptr.

Property Documentation

CurrentBehavior

Behavior Grail.Core.AIEntity.CurrentBehavior

get

get - Behavior currently assigned to this entity.

HasStagedBehavior

bool Grail.Core.AIEntity.HasStagedBehavior

get

Checks whether this entity has a behavior awaiting its execution.

Id

int Grail.Core.AIEntity.Id

get

A unique integer id assigned by AIManager during construction.

Name

string Grail.Core.AIEntity.Name

get

A name used for display and debug purposes.

Reasoner

Reasoner Grail.Core.AIEntity.Reasoner = nextEntityId++

getset

Reasoner assigned to this entity.

---

The documentation for this class was generated from the following file:

• GrailCore/source/AIEntity.cs
