Grail.Utility.Reasoners.UtilityReasoner Class Reference

Class responsible for assigning behaviors using Utility System algorithm. All considered behaviors are given a score designating their utility in current situation. Most suitable behavior is chosen based on those scores. More...

Inheritance diagram for Grail.Utility.Reasoners.UtilityReasoner:

Collaboration diagram for Grail.Utility.Reasoners.UtilityReasoner:

Public Member Functions
delegate bool	Validator (in int index)
	Validator. More...
override void	StageBehavior (AIEntity entity)
	Selects behavior, if able, and assigns it to entity. More...
void	SetSnapshotProduction (bool isEnabled)
	Tells reasoner whether it should produce debug snapshots of its state. More...
UtilityReasonerSnapshot	GetUtilityReasonerSnapshot ()
	Returns copy of current snapshot and clear the original data. More...
override ISnapshotGenerator	CreateSnapshotGenerator (int entityId)
	Creates object responsible for producing snapshots for this reasoner assigned to particular entity. More...
override void	ClearCache ()
	Called when assigning this reasoner to an entity. Clears internally stored data, which may be invalidated when assigned to a different entity. THIS METHOD SHOULD NOT BE CALLED BY THE USER. IT IS PUBLIC SO THAT THIS METHOD CAN BE USED BY ENTITY AND OVERRIDEN IN DIFFERENT MODULE More...

Protected Member Functions
	UtilityReasoner (List< BlueprintOption< Behavior, EntityBlackboardPair, AIEntity >> blueprintOptions, float persistence=0.1f)
	Constructor. More...
abstract void	GetBestOption< ContextType > (in List< SelectionOption< ContextType >> options, ref SelectionResult result, Validator validator)

Detailed Description

Class responsible for assigning behaviors using Utility System algorithm. All considered behaviors are given a score designating their utility in current situation. Most suitable behavior is chosen based on those scores.

Constructor & Destructor Documentation

UtilityReasoner()

Grail.Utility.Reasoners.UtilityReasoner.UtilityReasoner ( List< BlueprintOption< Behavior, EntityBlackboardPair, AIEntity >>  blueprintOptions, float  persistence = 0.1f  )

inlineprotected

Constructor.

Parameters

blueprintOptions	Blueprints mapped with evaluators.
persistence	Bonus score that currently executed behavior(or behavior from the top of the stack) gains during behavior selection. Persistence of 0 give no bonus at all, negative persistence causes unstable entity behaviors.

Member Function Documentation

ClearCache()

override void Grail.Utility.Reasoners.UtilityReasoner.ClearCache ( )

inlinevirtual

Called when assigning this reasoner to an entity. Clears internally stored data, which may be invalidated when assigned to a different entity. THIS METHOD SHOULD NOT BE CALLED BY THE USER. IT IS PUBLIC SO THAT THIS METHOD CAN BE USED BY ENTITY AND OVERRIDEN IN DIFFERENT MODULE

Reimplemented from Grail.Core.Reasoner.

CreateSnapshotGenerator()

override ISnapshotGenerator Grail.Utility.Reasoners.UtilityReasoner.CreateSnapshotGenerator ( int  entityId )

inlinevirtual

Creates object responsible for producing snapshots for this reasoner assigned to particular entity.

Parameters

entityId

ID of Entity to which this reasoner is assigned.

Returns

Created snapshot generator.

Reimplemented from Grail.Core.Reasoner.

GetUtilityReasonerSnapshot()

UtilityReasonerSnapshot Grail.Utility.Reasoners.UtilityReasoner.GetUtilityReasonerSnapshot ( )

inline

Returns copy of current snapshot and clear the original data.

Returns

Current state's snapshot.

SetSnapshotProduction()

void Grail.Utility.Reasoners.UtilityReasoner.SetSnapshotProduction ( bool  isEnabled )

inline

Tells reasoner whether it should produce debug snapshots of its state.

Parameters

isEnabled

StageBehavior()

override void Grail.Utility.Reasoners.UtilityReasoner.StageBehavior ( AIEntity  entity )

inlinevirtual

Selects behavior, if able, and assigns it to entity.

Parameters

entity

Owner entity to which selected behavior will be assigned.

Implements Grail.Core.Reasoner.

Validator()

delegate bool Grail.Utility.Reasoners.UtilityReasoner.Validator

(

in int

index

)

Validator.

---

The documentation for this class was generated from the following file:

• GrailUtilityAI/source/Reasoners/UtilityReasoner.cs
