The reasoner that encalpsulates the SimulatedGame technique which is based on Monte Carlo Tree Search. More...

Inheritance diagram for Grail.SimulatedGames.Reasoners.SimulatedGameReasoner:

Collaboration diagram for Grail.SimulatedGames.Reasoners.SimulatedGameReasoner:

Public Member Functions
	SimulatedGameReasoner (in ISimulatedGameStateTranslator gameStateTranslator, in ISimulatedActionTranslator actionTranslator, uint iterationsPerFrame, uint maxIterations=1000, uint maxRecalculationIterations=1000)
	Constructs a new SimulatedGameReasoner More...

void	RequestRecalculation (AIEntity entity)
	As documented, the ISimulatedActionTranslator translates the actions computed by SimulatedGame to behaviors. It constructs a plan (of such behaviors). Call this method at anytime if you want to stop applying behaviors (it will terminate the current one and clear all future ones). This should be called when the state desynchronizes, so the future plan should be invalidated. The method will make the reasoner perform additional simulations if computational budget allows for it. More...

void	SetSnapshotProduction (bool shouldProduceData)
	Calling this function makes the reasoner collect debug data. The GrailDebugger will call it automatically. More...

override void	StageBehavior (AIEntity entity)
	Runs reasoner's selection algorithm and assigns chosen behavior to provided entity. More...

SimulatedGamesReasonerSnapshot	ProduceDebugSnapshot ()
	This method returns debug snapshot of data collected so far by SimulatedGameSnapshotObserver. The GrailDebugger will call it. More...

override ISnapshotGenerator	CreateSnapshotGenerator (int entityId)

override void	ClearCache ()
	Called when assigning this reasoner to an entity. Clears internally stored data, which may be invalidated when assigned to a different entity. THIS METHOD SHOULD NOT BE CALLED BY THE USER. IT IS PUBLIC SO THAT THIS METHOD CAN BE USED BY ENTITY AND OVERRIDEN IN DIFFERENT MODULE More...

void	ClearDebugData ()

Properties
SimulatedGame	Game `[get]`
	Gets the SimulatedGame object that is currently created by the ISimulatedGameStateTranslator. More...

Behavior	FallbackBehavior `[set]`
	Set a fallback behavior if no valid behaviors are produced from actions returned by SimulatedGame. Please note that ISimulatedActionTranslator translates actions onto behaviors. More...

bool	IsComputing `[get]`
	Returns true is the reasoner has not finished computations (i.e. there are still simulations to perform). More...

uint	DebugSnapshotFirstIteration = false `[get, set]`
	You may limit the number of debug data collected to only data produced by simulations with numbers between [First, Last]. This method gets or sets the limit.

uint	DebugSnapshotLastIteration `[get, set]`
	You may limit the number of debug data collected to only data produced by simulations with numbers between [First, Last]. This method gets or sets the limit.

Detailed Description

The reasoner that encalpsulates the SimulatedGame technique which is based on Monte Carlo Tree Search.

Constructor & Destructor Documentation

◆ SimulatedGameReasoner()

Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.SimulatedGameReasoner	(	in ISimulatedGameStateTranslator	gameStateTranslator,
		in ISimulatedActionTranslator	actionTranslator,
		uint	iterationsPerFrame,
		uint	maxIterations = `1000`,
		uint	maxRecalculationIterations = `1000`
	)

inline

Constructs a new SimulatedGameReasoner

Parameters

gameStateTranslator	Object that instantiates SimulatedGame based on the current state of the actual game
actionTranslator	Object that translates actions from SimulatedGame (the result) onto plan consisting of behaviors in the actual game
iterationsPerFrame	The maximum number of iterations (simulations) per one game frame
maxIterations	The number of iterations to be performed before getting results - translating actions onto behaviors. This tells the reasoner "think for maxIterations before making decisions"
maxRecalculationIterations	When you call the RequestRecalculation function, the reasoner will use this pool of additional iterations.

Member Function Documentation

◆ ClearCache()

override void Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.ClearCache ( )

inlinevirtual

Called when assigning this reasoner to an entity. Clears internally stored data, which may be invalidated when assigned to a different entity. THIS METHOD SHOULD NOT BE CALLED BY THE USER. IT IS PUBLIC SO THAT THIS METHOD CAN BE USED BY ENTITY AND OVERRIDEN IN DIFFERENT MODULE

Reimplemented from Grail.Core.Reasoner.

◆ ProduceDebugSnapshot()

SimulatedGamesReasonerSnapshot Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.ProduceDebugSnapshot ( )

inline

This method returns debug snapshot of data collected so far by SimulatedGameSnapshotObserver. The GrailDebugger will call it.

Returns

◆ RequestRecalculation()

void Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.RequestRecalculation ( AIEntity entity )

inline

As documented, the ISimulatedActionTranslator translates the actions computed by SimulatedGame to behaviors. It constructs a plan (of such behaviors). Call this method at anytime if you want to stop applying behaviors (it will terminate the current one and clear all future ones). This should be called when the state desynchronizes, so the future plan should be invalidated. The method will make the reasoner perform additional simulations if computational budget allows for it.

◆ SetSnapshotProduction()

void Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.SetSnapshotProduction ( bool shouldProduceData )

inline

Calling this function makes the reasoner collect debug data. The GrailDebugger will call it automatically.

Parameters

shouldProduceData

◆ StageBehavior()

override void Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.StageBehavior ( AIEntity entity )

inlinevirtual

Runs reasoner's selection algorithm and assigns chosen behavior to provided entity.

Parameters

entity

Implements Grail.Core.Reasoner.

Property Documentation

◆ FallbackBehavior

Behavior Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.FallbackBehavior

set

Set a fallback behavior if no valid behaviors are produced from actions returned by SimulatedGame. Please note that ISimulatedActionTranslator translates actions onto behaviors.

◆ Game

SimulatedGame Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.Game

get

Gets the SimulatedGame object that is currently created by the ISimulatedGameStateTranslator.

◆ IsComputing

bool Grail.SimulatedGames.Reasoners.SimulatedGameReasoner.IsComputing

get

Returns true is the reasoner has not finished computations (i.e. there are still simulations to perform).

The documentation for this class was generated from the following file:

GrailSimulatedGames/source/Reasoners/SimulatedGameReasoner.cs
