Grail.FSM.FiniteStateMachine Class Reference

Class representing basic Finite State Machine. More...

Inheritance diagram for Grail.FSM.FiniteStateMachine:

Collaboration diagram for Grail.FSM.FiniteStateMachine:

Public Member Functions
	FiniteStateMachine (Dictionary< IState, Func< IState >> transitionFunctions, IState initialState, string stateMachineName="state machine")
	Constructor. Parameters transitionFunctions Transition functions for states. Functions should return the next state or, null - if no transition is to be made. initialState State with which this state machine will be initialized. stateMachineName Name of this state machine. More...
	FiniteStateMachine (List<(IState sourceState, IState destinationState, Func< bool > condition)> transitions, IState initialState, string stateMachineName="state machine")
	Constructor. Parameters transitions Transition function for states defined as (source state, destination state, condition). initialState State with which this state machine will be initialized. stateMachineName Name of this state machine. More...
override void	Enter ()
	Called once after machine enters this state. More...
override void	Update (float deltaTime)
	Performs state transition, if one is required, and runs update for resulting state. More...
Public Member Functions inherited from Grail.FSM.DefaultState
virtual void	Exit ()
	Called once after machine exits this state. More...

Public Attributes
IState	CurrentState => currentState
	Current state. More...

Additional Inherited Members
Protected Member Functions inherited from Grail.FSM.DefaultState
	DefaultState (string stateName)
Properties inherited from Grail.FSM.DefaultState
string	Name [get]
	Name of this state. More...
Properties inherited from Grail.FSM.IState
string	Name [get]
	Name of this state. More...

Detailed Description

Class representing basic Finite State Machine.

Constructor & Destructor Documentation

FiniteStateMachine() [1/2]

Grail.FSM.FiniteStateMachine.FiniteStateMachine ( Dictionary< IState, Func< IState >>  transitionFunctions, IState  initialState, string  stateMachineName = "state machine"  )

inline

Constructor.

Parameters

transitionFunctions	Transition functions for states. Functions should return the next state or, null - if no transition is to be made.
initialState	State with which this state machine will be initialized.
stateMachineName	Name of this state machine.

FiniteStateMachine() [2/2]

Grail.FSM.FiniteStateMachine.FiniteStateMachine ( List<(IState sourceState, IState destinationState, Func< bool > condition)>  transitions, IState  initialState, string  stateMachineName = "state machine"  )

inline

Constructor.

Parameters

transitions	Transition function for states defined as (source state, destination state, condition).
initialState	State with which this state machine will be initialized.
stateMachineName	Name of this state machine.

Member Function Documentation

Enter()

override void Grail.FSM.FiniteStateMachine.Enter ( )

inlinevirtual

Called once after machine enters this state.

Reimplemented from Grail.FSM.DefaultState.

Update()

override void Grail.FSM.FiniteStateMachine.Update ( float  deltaTime )

inlinevirtual

Performs state transition, if one is required, and runs update for resulting state.

Reimplemented from Grail.FSM.DefaultState.

Member Data Documentation

CurrentState

IState Grail.FSM.FiniteStateMachine.CurrentState => currentState

Current state.

---

The documentation for this class was generated from the following file:

• GrailFiniteStateMachine/source/FiniteStateMachine.cs
