Grail.FSM.FSMBehavior Class Reference

Class responsible for assigning behaviors using Finite State Machine algorithm. More...

Inheritance diagram for Grail.FSM.FSMBehavior:

Collaboration diagram for Grail.FSM.FSMBehavior:

Public Member Functions
	FSMBehavior (List<(IState sourceState, IState destinationState, Func< bool >)> transitions, IState initialState, string stateMachineName)
	Constructor. More...
	FSMBehavior (FiniteStateMachine stateMachine)
sealed override void	Start (AIEntity owner)
sealed override void	Update (AIEntity owner, float deltaTime)
sealed override void	Finish (AIEntity owner, in BehaviorStatus status)
override bool	IsFinished (AIEntity owner)
Public Member Functions inherited from Grail.Core.Behavior
	Behavior (Behavior recoveryBehavior=null)
virtual bool	IsLegal (AIEntity owner)
virtual bool	IsInterruptible ()

Additional Inherited Members
Public Attributes inherited from Grail.Core.Behavior
virtual Behavior	RecoveryBehavior => recoveryBehavior
Protected Attributes inherited from Grail.Core.Behavior
Behavior	recoveryBehavior
Properties inherited from Grail.Core.Behavior
BehaviorStatus	Status [get, set]

Detailed Description

Class responsible for assigning behaviors using Finite State Machine algorithm.

Constructor & Destructor Documentation

FSMBehavior()

Grail.FSM.FSMBehavior.FSMBehavior ( List<(IState sourceState, IState destinationState, Func< bool >)>  transitions, IState  initialState, string  stateMachineName  )

inline

Constructor.

Parameters

transitions	Considerations used to determine possible transitions from given state.
initialState	State with which this state machine will be initialized.
stateMachineName	Name of this state machine.

Member Function Documentation

Finish()

sealed override void Grail.FSM.FSMBehavior.Finish ( AIEntity  owner, in BehaviorStatus  status  )

inlinevirtual

Invoked after the behavior is finished or interrupted

Parameters

owner

- the entity executing this behavior

Reimplemented from Grail.Core.Behavior.

IsFinished()

override bool Grail.FSM.FSMBehavior.IsFinished ( AIEntity  owner )

inlinevirtual

Parameters

owner

- the entity executing this behavior

Reimplemented from Grail.Core.Behavior.

Start()

sealed override void Grail.FSM.FSMBehavior.Start ( AIEntity  owner )

inlinevirtual

Invoked after the behavior is assigned to AIEntity

Parameters

owner

- the entity executing this behavior

Reimplemented from Grail.Core.Behavior.

Update()

sealed override void Grail.FSM.FSMBehavior.Update ( AIEntity  owner, float  deltaTime  )

inlinevirtual

Invoked on each AIManager update

Parameters

owner

- the entity executing this behavior

Reimplemented from Grail.Core.Behavior.

---

The documentation for this class was generated from the following file:

• GrailFiniteStateMachine/source/Behaviors/FSMBehavior.cs
